R.R. 500 Rotary Tiller / Hydraulic Rotaridger
R.R. 500 Rotary Tiller / Hydraulic Rotaridger
Overview
The R.R. 500 is a heavy-duty, versatile rotary tiller designed to meet the needs of modern farming. Built with the latest technology, this tiller is suitable for all soil types and is particularly efficient for making ridgers for row crops such as sugarcane, potatoes, and chilies, as well as for opening furrows for water flow.
Key Specifications
- Size: 5 Ft
- Overall Dimensions (mm): 2032 X 1447 X 1209
- Tillage Width (mm): 1745
- Tillage Depth: 160-200 mm
- Gear Drive: 13 X 23 Heavy / Multi-Speed
- Gear Box Type: Multi-Speed Gearbox
- Side Transmission: Gear Driven, Oil Bath
- PTO RPM: 540
- Number of Blades: 36
- Blade Type: L-Type / Jf-Type
- Net Weight: 625 kg
- Tractor Power Requirement: 45 to 70 Hp
- Frame Sheet Thickness: 5 mm
- Side Gear Ratio: 21 X 36 X 26
- Crown Pinion Size: 13 X 23
- Ridger Frame Size: 100 X 100 Pipe / 5 mm Thickness
- Working Ridger Width: 1000 mm to 1830 mm
- Ridger Adjustment Setting: Hydraulic System
- Ridger Point Material: Boron Steel
Features
- Multi-Speed Gearbox: Allows for versatile use across different soil types and conditions.
- Adjustable Lower Hitch Brackets: For easy attachment and detachment.
- High-Quality Japan Blades: Ensures precision and durability.
- Gear Driven Side Transmission: In oil bath for smooth operation and longevity.
- Adjustable Skides: For precise control over tilling depth.
- Rear Board Springs: Enhances stability and performance during operation.
- Mechanical Oil Seals: Protects internal components, reducing maintenance needs.
- Heavy Multi-Speed Gearbox: Designed for long-lasting performance in tough conditions.
- Adjustable Link Set: Provides flexibility for various field conditions.
Advantages
- Versatile Use: Suitable for all soil types.
- Efficient Design: Equipped with a spring-loaded adjustable trailing board for enhanced efficiency.
- Durable Structure: Built to last, with a sturdy frame and high-quality materials.
- Low Maintenance: Designed for reduced fuel consumption and minimal upkeep.
- Multiple Applications: Ideal for row crops such as sugarcane, potatoes, and chilies, as well as furrow opening for water flow
