Overview
Our Rotary Tiller is engineered with a special ridger design, offering versatile performance across different soil types and agricultural needs. Available in multiple sizes, it is built to provide efficient tillage and ridging for a wide range of farming applications.
1. 5 Ft Rotary Tiller
- Overall Dimensions (mm): 1784 X 957 X 1209
- Tillage Width (mm): 1745
- Tillage Depth: 160-200 mm
- Gear Box Type: Multi-Speed
- Side Transmission: Gear Drive
- PTO RPM: 540
- Number of Blades: 36
- Net Weight: 485 kg
- Tractor Power Requirement: 35 Hp and above
- Frame Sheet Thickness: 5 mm
- Side Gear Ratio: 21 X 36 X 26
- Crown Pinion: 13 X 23
2. 6 Ft Rotary Tiller
- Overall Dimensions (mm): 2030 X 957 X 1209
- Tillage Width (mm): 2030
- Tillage Depth: 160-200 mm
- Gear Box Type: Multi-Speed
- Side Transmission: Gear Drive
- PTO RPM: 540
- Number of Blades: 42
- Net Weight: 520 kg
- Tractor Power Requirement: 45 Hp and above
- Frame Sheet Thickness: 5 mm
- Side Gear Ratio: 21 X 36 X 26
- Crown Pinion: 13 X 23
3. 7 Ft Rotary Tiller
- Overall Dimensions (mm): 2290 X 957 X 1209
- Tillage Width (mm): 2290
- Tillage Depth: 160-200 mm
- Gear Box Type: Multi-Speed
- Side Transmission: Gear Drive
- PTO RPM: 540
- Number of Blades: 48
- Net Weight: 560 kg
- Tractor Power Requirement: 50 Hp and above
- Frame Sheet Thickness: 5 mm
- Side Gear Ratio: 21 X 36 X 26
- Crown Pinion: 13 X 23
4. 8 Ft Rotary Tiller
- Overall Dimensions (mm): 2500 X 957 X 1209
- Tillage Width (mm): 2610
- Tillage Depth: 160-200 mm
- Gear Box Type: Multi-Speed
- Side Transmission: Gear Drive
- PTO RPM: 540
- Number of Blades: 54
- Net Weight: 592 kg
- Tractor Power Requirement: 55 Hp and above
- Frame Sheet Thickness: 5 mm
- Side Gear Ratio: 21 X 36 X 26
- Crown Pinion: 13 X 23
Common Features Across All Models
- Special Linkage Design: Ensures compatibility with a wide range of tractors and farming conditions.
- High-Quality L-Type/Jf-Type Blades: Designed for precision cutting and durability.
- Durable Construction: 5 mm thick frame sheet for enhanced longevity and resilience.
- Optimized Gear Ratios: Side gear ratio of 21 X 36 X 26 and crown pinion ratio of 13 X 23 for smooth and efficient operation.
